本篇，在ASP.NET MVC4下实现单个图片上传，具体功能包括：
- 1、在客户端选择图片，并限制图片的大小和格式
- 2、在客户端上传图片，并显示预览图
- 3、在服务端限制图片的大小和格式
- 4、在服务端保存图片时，把图片裁剪成某个固定尺寸
本篇源码在：https://github.com/darrenji/FileUploadInMVC
实现的大致思路是：
- 客户端限制图片大小和格式，通过写一个jQuery插件来实现
- 服务端实现图片裁剪，通过使用ImageSize组件来实现
首先是一个用来承载上传信息的类：
| public class UploadFileResult | |
| { | |
| //带后缀的名称，比如xxx.jpg | |
| public string FileName { get; set; } | |
| //图片的字节数 | |
| public int Length { get; set; } | |
| //图片的类型：image/jpeg | |
| public string Type { get; set; } | |
| public bool IsValid { get; set; } | |
| public string Message { get; set; } | |
| //图片的完整路径：~/AjaxUpload/20141112_large.jpg | |
| public string FilePath { get; set; } | |
| } |
在HomeController中，需要提供一个接收前端上传文件并返回json格式的Action方法，还需要提供一个根据文件名删除图片的Action方法。
| using System; | |
| using System.Collections.Generic; | |
| using System.IO; | |
| using System.Linq; | |
| using System.Web; | |
| using System.Web.Mvc; | |
| using ImageResizer; | |
| using MvcApplication10.Models; | |
| namespace MvcApplication10.Controllers | |
| { | |
| public class HomeController : Controller | |
| { | |
| public ActionResult Index() | |
| { | |
| return View(); | |
| } | |
| //接收上传图片 | |
| [] | |
| public ActionResult UploadFile() | |
| { | |
| //允许的图片格式 | |
| var allowedExtensions = new[] { ".png", ".gif", ".jpg", ".jpeg" }; | |
| //返回给前台的结果，最终以json返回 | |
| List<UploadFileResult> results = new List<UploadFileResult>(); | |
| //遍历从前台传递而来的文件 | |
| foreach (string file in Request.Files) | |
| { | |
| //把每个文件转换成HttpPostedFileBase | |
| HttpPostedFileBase hpf = Request.Files[file] as HttpPostedFileBase; | |
| //如果前台传来的文件为null，继续遍历其它文件 | |
| if (hpf.ContentLength == 0 || hpf == null) | |
| { | |
| continue; | |
| } | |
| else | |
| { | |
| if (hpf.ContentLength > 1024*1024) //如果大于规定最大尺寸 | |
| { | |
| results.Add(new UploadFileResult() | |
| { | |
| FileName = "", | |
| FilePath = "", | |
| IsValid = false, | |
| Length = hpf.ContentLength, | |
| Message = "图片尺寸不能超过1024KB", | |
| Type = hpf.ContentType | |
| }); | |
| } | |
| else | |
| { | |
| var extension = Path.GetExtension(hpf.FileName); | |
| if (!allowedExtensions.Contains(extension))//如果文件的后缀名不包含在规定的后缀数组中 | |
| { | |
| results.Add(new UploadFileResult() | |
| { | |
| FileName = "", | |
| FilePath = "", | |
| IsValid = false, | |
| Length = hpf.ContentLength, | |
| Message = "图片格式必须是png、gif、jpg或jpeg", | |
| Type = hpf.ContentType | |
| }); | |
| } | |
| else | |
| { | |
| //给上传文件改名 | |
| string date = DateTime.Now.ToString("yyyyMMddhhmmss"); | |
| //目标文件夹的相对路径 ImageSize需要的格式 | |
| string pathForSaving = Server.MapPath("~/AjaxUpload/"); | |
| //目标文件夹的相对路径 统计文件夹大小需要的格式 | |
| string pathForSaving1 = Server.MapPath("~/AjaxUpload"); | |
| //在根目录下创建目标文件夹AjaxUpload | |
| if (this.CreateFolderIfNeeded(pathForSaving)) | |
| { | |
| //保存小图 | |
| var versions = new Dictionary<string, string>(); | |
| versions.Add("_small", "maxwidth=400&maxheight=250&format=jpg"); | |
| //versions.Add("_medium", "maxwidth=200&maxheight=200&format=jpg"); | |
| //versions.Add("_large", "maxwidth=600&maxheight=600&format=jpg"); | |
| //保存各个版本的缩略图 | |
| foreach (var key in versions.Keys) | |
| { | |
| hpf.InputStream.Seek(0, SeekOrigin.Begin); | |
| ImageBuilder.Current.Build(new ImageJob( | |
| hpf.InputStream, | |
| pathForSaving + date + key, //不带后缀名的图片名称 | |
| new Instructions(versions[key]), | |
| false,//是否保留原图 | |
| true));//是否增加后缀 | |
| } | |
| results.Add(new UploadFileResult() | |
| { | |
| FileName = date + "_small" + ".jpg", | |
| FilePath = Url.Content(String.Format("~/AjaxUpload/{0}", date + "_small" + ".jpg")), | |
| IsValid = true, | |
| Length = hpf.ContentLength, | |
| Message = "上传成功", | |
| Type = hpf.ContentType | |
| }); | |
| } | |
| } | |
| } | |
| } | |
| } | |
| return Json(new | |
| { | |
| filename = results[0].FileName, | |
| filepath=results[0].FilePath, | |
| isvalid=results[0].IsValid, | |
| length=results[0].Length, | |
| message=results[0].Message, | |
| type=results[0].Type | |
| }); | |
| } | |
| //根据文件名删除文件 | |
| [] | |
| public ActionResult DeleteFileByName(string smallname) | |
| { | |
| string pathForSaving = Server.MapPath("~/AjaxUpload"); | |
| System.IO.File.Delete(Path.Combine(pathForSaving, smallname)); | |
| return Json(new | |
| { | |
| msg = true | |
| }); | |
| } | |
| //根据相对路径在项目根路径下创建文件夹 | |
| private bool CreateFolderIfNeeded(string path) | |
| { | |
| bool result = true; | |
| if (!Directory.Exists(path)) | |
| { | |
| try | |
| { | |
| Directory.CreateDirectory(path); | |
| } | |
| catch (Exception) | |
| { | |
| result = false; | |
| } | |
| } | |
| return result; | |
| } | |
| } | |
| } |
在Home/Index.cshtml中，使用checkFileTypeAndSize.js插件来限制上传图片的大小和格式，使用FormData对象来接收图片文件并传递给服务端，客户端接收到服务端json数据动态创建表格行把预览图显示出来。
| @{ | |
| ViewBag.Title = "Index"; | |
| Layout = "~/Views/Shared/_Layout.cshtml"; | |
| } | |
| <style type="text/css"> | |
| #msg { | |
| color: red; | |
| } | |
| </style> | |
| <form id="file_upload_form" method="post" enctype="multipart/form-data" action=""> | |
| <input name="file" id="file" size="27" type="file" /> | |
| <img src="~/images/ajax-loader.gif" id="indicator" style="display: none;" /> | |
| <br /> | |
| <div id="imgArea"> | |
| <table id="tbl"> | |
| <tbody> | |
| </tbody> | |
| </table> | |
| </div> | |
| <div> | |
| <span id="msg"></span> | |
| </div> | |
| </form> | |
| @section scripts | |
| { | |
| <script src="~/Scripts/checkFileTypeAndSize.js"></script> | |
| <script type="text/javascript"> | |
| $(function() { | |
| $("#file").checkFileTypeAndSize({ | |
| allowedExtensions: ['jpg','jpeg','gif','png'], | |
| maxSize: 1024, //最大允许1024KB，即1MB | |
| success: function () { | |
| //显示进度提示 | |
| $('#indicator').css("display", "block"); | |
| //清空提示内容 | |
| $('#msg').text(''); | |
| if ($('#fn').text().length > 0) { | |
| //删除图片 | |
| deleteImg(); | |
| } | |
| //上传文件数据准备 | |
| var fd = new FormData(); | |
| fd.append('image', $('#file')[0].files[0]); | |
| $.ajax({ | |
| url: '@Url.Action("UploadFile","Home")', | |
| type: "POST", | |
| data: fd, | |
| contentType: false, | |
| cache: false, | |
| processData: false, | |
| dataType: 'json', | |
| success: function (data) { | |
| //隐藏进度提示 | |
| $('#indicator').css("display", "none"); | |
| if (data.isvalid) { | |
| //$('#fileTemplate').tmpl(data).appendTo('#imgArea'); | |
| createTableTr(); | |
| $('#thumb').attr('src', data.filepath); | |
| $('#fn').text(data.filename); | |
| } else { | |
| $('#msg').text(data.message); | |
| } | |
| } | |
| }); | |
| }, | |
| extensionerror: function () { | |
| //alert('允许的格式为：jpg,jpeg,gif,png'); | |
| $('#msg').text('允许的格式为：jpg,jpeg,gif,png'); | |
| return; | |
| }, | |
| sizeerror: function () { | |
| //alert('最大尺寸1024KB,即1MB'); | |
| $('#msg').text('最大尺寸1024KB,即1MB'); | |
| return; | |
| } | |
| }); | |
| }); | |
| //删除图片 | |
| function deleteImg() { | |
| $.ajax({ | |
| cache: false, | |
| url: '@Url.Action("DeleteFileByName", "Home")', | |
| type: "POST", | |
| data: { smallname: $('#fn').text() }, | |
| success: function (data) { | |
| if (data.msg) { | |
| $('#fn').parent().parent().remove(); | |
| } | |
| }, | |
| error: function (jqXhr, textStatus, errorThrown) { | |
| alert("出错了 '" + jqXhr.status + "' (状态: '" + textStatus + "', 错误为: '" + errorThrown + "')"); | |
| } | |
| }); | |
| } | |
| //创建表格 | |
| function createTableTr() { | |
| var table = $('#tbl'); | |
| table.append("<tr><td><img id='thumb' /></td><td colspan='2'><span id='fn'></span></td></tr>"); | |
| } | |
| </script> | |
| } |
