前言
首先要说明，使用HBuilder或者vs Code工具开发的时候，在微信开发者工具调试的时候，我们使用本地图片是OK的，但是一旦放到真机上调试的时候，图片就显示不出来。
先看uniapp官网对背景图片的说明
错误用法
<template>
<view class="home" :style="{backgroundImage:`url(${homeBg})`">
<!--你的内容-->
</view>
</template>
<script setup>
import homeBg from "@/static/img/home/home_bg.png"
const homeBg = homeBg
</script>
<style lang="scss">
</style>
或者
<template>
<view class="home">
<!--你的内容-->
</view>
</template>
<script setup>
</script>
<style lang="scss">
.home {
background-image: url('~@/static/img/home/home_bg.png');
}
</style>
解决方式
将图片资源放到服务器，以https://形式使用
将图片转为base64格式使用
background使用image标签替代
动态将图片转base64
在工具文件夹创建common.js文件
//解决小程序端真机图片不展示
/**
* 动态绑定的使用方式 例如首页使用：
* import common from '@/utils/common'
* :style="{
backgroundImage: `url(${common.urlTobase('home', 'home-bg')})`,
}"
*/
/**
* 获取本地图
* @param folder // 文件夹名字 如 /static/images/home
* @param fileName // 文件名 如 home-bg
* @param format // 文件类型 如 png jpg
* @returns {*|string}
*/
// #ifdef MP-WEIXIN
const urlTobase = (folder, fileName, format = "png") => {
let img = `/static/images/${folder}/${fileName}.${format}`,
imgBase = wx.getFileSystemManager().readFileSync(img, "base64"),
/* console.log(
"图片转换成功+++++++++++++++++++++++++++++"
); */
return baseUrl;
};
// #endif
export default {
urlTobase,
};
在vue文件中使用方式
<template>
<view class="home" :style="{backgroundImage:`url(${common.urlTobase('home', 'home-bg')})`">
<!--你的内容-->
</view>
</template>
<script setup>
import common from '@/utils/common'
</script>
<style lang="scss">
</style>
手动将图片转base64作为参数使用
在静态资源文件夹下创建一个sass文件，如base64-img-store.scss文件
图片在线转换base64编码-在线base64编码转换成图片工具 http://www.jsons.cn/img2base64/
// 解决小程序端真机图片不展示
/* *
* 需要在根目录下uni.scss下全局引入
* 在css中的使用方式 例如首页使用：
* .home{
* background-image: $home_bg_base_code;
* background-size: cover;
* }
* 图片在线转换base编码-在线base64编码转换成图片工具 http://www.jsons.cn/img2base64/
* 将图片转换好的base放到对应url里
* 样式变量名可以自行定义 例如：$home_bg_base_code 或 $a 或 $bg
*/
然后在根目录下uni.scss下引入
@import "@/static/style/common/base-img-store.scss";
在vue文件中使用方式
<template>
<view class="home">
<!--你的内容-->
</view>
</template>
<script setup>
</script>
<style lang="scss">
.home {
background-image: $home_bg_base_code;
background-size: cover;
}
</style>
到此结束。
